Wayfarers' Chapel, Palos Verdes, California: Sketch sections, plans and elevations for the vestry dressing table and lavatory

Part of:

People:

Lloyd Wright (architect)
Lloyd Wright (draughtsman)

Title:

Wayfarers' Chapel, Palos Verdes, California: Sketch sections, plans and elevations for the vestry dressing table and lavatory

Date:

1955 ?

Description:

- Three of these drawings for Wayfarers' Chapel, Palos Verdes, California, have been crossed out, including those for the brick mould, the "wood stop" and the light soffit.

Form:
drawings

Quantity / Object type:
1 drawing(s)

Stage and Purpose:

design development drawings
detail drawings

Technique and media:

Graphite

Dimensions:

sheet (irreg.; approx.): 51,4 x 64,5 cm

Reference number:

DR1987:0591

Drawing Type:

line drawings
freehand drawings

Method of Projection:

sketch elevations (drawings)
sketch plans (drawings)
sketch sections (orthographic drawings)

Point of View:

general views
partial views
interior view

Physical characteristics and technical requirements:

- Sheet is 'L' shaped and folded at both ends.

Inscription:

inscribed and numbered - by the draughtsman, in graphite, u.l.: "ELEVATION ... / PLAN OF DRESSING TABLE"; c.l.: "CHROMEDGE"; l.l.: "ELEVATION OF PULLMAN SECTION / PLAN OF PULLMAN IN / WOMENS TOILET"; c.r.: "BRICK MOULD / SECT THRU LIGHT SOFFIT / WOOD STOP [all three views and titles are crossed out]"; b.: "#229" [job number]; and in various locations: with measurements, notes and calculations

Location:

United States

Subject:

architecture
interior design

Subject Descriptive Terms:

lavatory (room)
rest room
dressing table

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
