Partial elevations and sectional details for a door and mailbox and for type A and type C housing units, Hellerhof Housing Estate, Frankfurt am Main, Germany
Partial elevations and sectional details for a door and mailbox and for type A and type C housing units, Hellerhof Housing Estate, Frankfurt am Main, Germany
People:
  • Mart Stam (draughtsman)
  • Mart Stam (architect)
  • Aktiengesellschaft Hellerhof (client)
Title:

Partial elevations and sectional details for a door and mailbox and for type A and type C housing units, Hellerhof Housing Estate, Frankfurt am Main, Germany

Date:

1928-1932

Form:
drawings
Quantity / Object type:
1 drawing(s)
Stage and Purpose:
  • design development drawings
  • detail drawings
Technique and media:

Graphite

Dimensions:

sheet: 90.0 x 13.0 cm

Reference number:

DR1984:1133

Drawing Type:
  • line drawings
  • mechanical drawings (tool-aided drawings)
Method of Projection:
  • sections (orthographic drawings)
  • elevations (drawings)
Point of View:
  • partial views
  • exterior views
  • interior views
Physical characteristics and technical requirements:

- A graphite border frames the drawing. Small losses throughout edge of sheet.

Inscription:

numbered and inscribed - by the draughtsman ?, in pen and black ink, l.r.: "BLATT 495 / HELLERHOF 1930 TÜR U.BRIEFKASTEN." stamped - in purple ink, l.r.: "STAM u. MOSER, ARCHITEKTEN / NEUE MAINZERSTR.18, II.- FRANKFURT a.M." inscribed - by the draughtsman, in graphite, throughout: with dimensions and specifications inscribed - by an unknown hand, in graphite, u.r.: "90//110"

Subject:
  • architecture
Subject Descriptive Terms:
  • door
  • mailbox
Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
Copyright:

© Estate of Mart Stam
