First floor plan and section for a type B and a type EO housing unit for Block VIII, Hellerhof Housing Estate, Frankfurt am Main, Germany
First floor plan and section for a type B and a type EO housing unit for Block VIII, Hellerhof Housing Estate, Frankfurt am Main, Germany
People:
  • Mart Stam (architect)
  • Mart Stam (draughtsman)
  • Aktiengesellschaft Hellerhof (client)
Title:

First floor plan and section for a type B and a type EO housing unit for Block VIII, Hellerhof Housing Estate, Frankfurt am Main, Germany

Date:

22 August 1930, revised 17 September 1930

Form:
drawings
Quantity / Object type:
1 drawing(s)
Stage and Purpose:
  • design development drawing
Technique and media:

Graphite

Dimensions:

sheet: 34.9 x 80.0 cm

Reference number:

DR1984:1181

Drawing Type:
  • line drawing
  • mechanical drawing (tool-aided drawing)
Method of Projection:
  • plan (drawing)
  • section
Point of View:
  • interior views
  • plan view
Physical characteristics and technical requirements:

- A graphite border frames the drawing.

Inscription:

stamped - in purple ink, l.r.: "fertiggestellt / den [with date and drawing number] / abgeändert / den [with date] MST. [with scale] / ARCH. MART STAM, FRANKFURT AM MAIN" inscribed and numbered - by the draughtsman, in pen and black ink, c.r.: with specifications; and l.r.: "593" inscribed and dated - by the draughtsman, in graphite, l.r.: "OBERRGESCHOSS TYP B+EO BLOCK VIII" and "HELLERHOF 1930 / BL. [593] / 22.8.1930 / 17.9. / [with scale]" [within stamp]; and throughout: with dimensions, room functions, and plan and section orientation inscribed - by an unknown hand, in graphite, b.: "1x 4r[?]" inscribed - by an unknown hand, in graphite, u.r.: "80//34"
