Contract drawing of the first floor (bedroom) plan for The Wick, Richmond Hill

People:

Robert Mylne (architect)
Daniel Pinder (contractor)

Title:

Contract drawing of the first floor (bedroom) plan for The Wick, Richmond Hill

Date:

1775

Form:
drawings

Quantity / Object type:
1 drawing(s)

Stage and Purpose:

contract drawing

Technique and media:

Pen and black ink, black and yellow wash on laid paper

Dimensions:

Sheet: 31.4 x 46.6 cm

Reference number:

DR1983:0830

Method of Projection:

plan (drawing)

Inscription:

inscribed - Plan of the Bed - Chamber - Story (lower centre, brown ink, artist'shand), (rooms are labelled and there are several measurements, all in brownink, artist's hand), 82 (lower right, graphite, later hand), Copingfor/35=0/1=5 wall/[illegible word]/20 30=0/1=0 (verso, graphite, lower left,possibly contemporary hand) scale: 10 feet = 4.9 cm. (with scale bar, lowercentre, black and brown ink) signature: June 12th 1775 Dan.l Pinder/RobertMylne (lower right, brown ink)

Location:

Richmond; Surrey; England; United Kingdom;

Subject:

architecture

Subject Descriptive Terms:

dwelling

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
