Side elevation of a mausoleum in a wooded setting

People:

Unknown, early 19th century (aquatinter)
Unknown, early 19th century (etcher)
Unknown, early 19th century (architect)

Title:

Side elevation of a mausoleum in a wooded setting

Date:

early 19th century

Description:

- Prints DR1987:0064 - DR1987:0069 are probably for a mausoleum and include 3 elevations, 2 sections and 1 plan. The mausoleum is almost square in plan with a protruding semidomed apse and a portico "in antis" consisting of two Tuscan engaged pillars supporting a thick architrave which runs around the exterior of the mausoleum. The structure is raised on a podium and has a gabled roof perched high above the main structure, surmounted by a cupola crowned with an orb and cross. On the interior, the barrel vaulted nave is separated from the apse by a rood-like screen pierced by three doors and by a Corinthian colonnade. The chancel and apse areas are slightly raised and are accessed by a flight of stairs. A spiral staircase on the left side of the narthex provides access to the gallery, upper level, and cupola. A tomb monument or sarcophagus, composed of a rectangular masonry slab surmounted by a vertical slab decorated with a recumbent female figure, is located at the centre of the lateral wall of the nave under the fanlight.

Form:
works of art

Quantity / Object type:
1 print(s)

Stage and Purpose:

presentation drawing (gift)
record drawing

Technique and media:

Etching and aquatint

Dimensions:

plate mark: 32.6 x 36.7 cm sheet: 47.5 x 59.1 cm

Reference number:

DR1987:0064

Drawing Type:

finished drawing
rendering

Method of Projection:

elevation (drawing)

Physical characteristics and technical requirements:

- Four holes at b. where sheet was formerly sewn.

Inscription:

uninscribed - object uninscribed

Subject:

architecture

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
