Ground floor plan, Nuovo cimitero San Cataldo, Modena, Italy
Ground floor plan, Nuovo cimitero San Cataldo, Modena, Italy
Part of:
People:
  • Aldo Rossi (archive creator)
  • Aldo Rossi (architect)
  • Gianni Braghieri (architect)
Title:

Ground floor plan, Nuovo cimitero San Cataldo, Modena, Italy

Date:

20 January 1976

Form:
drawings
Quantity / Object type:
1 drawing(s)
Stage and Purpose:
  • presentation drawing (proposal)
Extent and medium:
  • 1 sepia diazotype on plastic film
Dimensions:

sheet: 108,5 x 120,8 cm

Reference number:

AP142.S1.D29.P7.6

Drawing Type:
  • line drawing
  • mechanical drawing (tool-aided drawing)
Method of Projection:
  • ground plan
Inscription:

Printed and dated, in title block, l.l.: "(...) PIANTA PIANO TERRENO / LOCULI PARTE PERIMITRALE - PORTICO - SERVIZI / PERCORSO DI COLLEGAMENTO / (...) 20.1.1976"; printed, throughout the floor plan: with measurements and indications of the usage of the rooms

Credit line:
Aldo Rossi fonds
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
Copyright:

© Eredi Aldo Rossi / Fondazione Aldo Rossi

Language of material:
  • Italian
Folder Number:

142-0045 XL
