• Louis I. Kahn (architect)
• Louis I. Kahn (draughtsman)
• August E. Komendant (role unspecified)

Perspective sketches for the Italian Biennale pavilion and sketches for the Palazzo dei Congressi, Venice, Italy

1968 or 1969

- While the main drawings on this sheet show the Venice Bienalle Pavilion, the drawings below these and the lowest annotation relate to the Palazzi dei Congressi.

• dessins conceptuels
• design development drawings

Crayon (black and coloured) on translucent paper

sheet (irr.): 57 × 64 cm (22 7/16 × 25 3/16 in.)

DR1982:0010

• line drawing
• sketches

• perspective drawings

• interior views

- Sheet has irregular edges, especially at l., and pinholes at corners. Repairs have been made to the t. corners. Smudging across sheet has been stabilized with an unknown fixative.

inscribed - by the draughtsman, in black conté crayon, c.: "court / canal / The Happening in the court of the Bienalle [sic] / opening on the building tiers and the raised / Terraces of the stage overlook the activity / in the court. The great doors are closed. The roof is / shown half closed. Every day a new event"; l.l.: "The FIVE major divisions of the / court facade are 30' on center. Flanking / them are the stair entrances and service passages / at the extreme ends. / The wide divisions are chosen to offer [illeg.] the non directional / slabs of the floors 30' x 30. and [illeg.] ideas for the enclosures / It would be possible to vary the facade of the 3 levels."; l.c.: "The Auditorium of Congress Hall / is like a long plaza with gentle / slope"; and l.c. to l.r.: "The reception-like a street with niches-At night / it becomes the Ball Room. At times the street exhibits / the spirit of the Congress / at times it is of procession / or of happening-then the niches are the places of the onlookers."

• architecture
• ingénierie

• skylights
• canal
• exhibition building
