Casa Dragone e Paggi [Dragone and Paggi house], Milan, Italy (1987)

Casa Dragone e Paggi [Dragone and Paggi house], Milan, Italy (1987)

Part of

People

  • Umberto Riva (archive creator)

Title

Casa Dragone e Paggi [Dragone and Paggi house], Milan, Italy (1987)

Dates of creation

1987

Level of archival description

Project

Extent and Medium

  • 63 drawings (including 7 reprographic copies)

Scope and Content

This project series documents the Casa Dragone e Paggi, two built apartments in a condominium building in Milan, Italy. Riva worked on this project from 1987-1988. The aim of the project was to convert a single appartment into two smaller units. The project is recorded through design development drawings, including elevations, floor plans, sections, furnishing details, and sketches.

Reference Number

AP180.S1.1987.PR02

Location

Milan Italy

Inventory

  • Actions:
    See more Close
    • Reference Number: AP180.S1.1987.PR02.001
    • Title: Elevations, floor plans, sections, furnishings details, and sketches, Casa Dragone e Paggi, Milan, Italy
    • Dates of creation: ca. 1987
    • Form: drawings
    • Catalogued items within this file 0

    People:

    • Umberto Riva (archive creator)
    • Umberto Riva (architect)

    Quantity / Object type:

    1 File

    Extent and Medium:

    • 56 drawings
    • 7 reprographic copies

    Dimensions:

    sheet (smallest); 49 x 42 cm sheet (largest): 62 x 100 cm

    Physical Description:

    The drawings were previously rolled and tend to roll back on themselves.

    Credit line:

    When citing the collection as a whole, use the following citation:
    Umberto Riva fonds
    Collection Centre Canadien d'Architecture/
    Canadian Centre for Architecture, Montréal;
    Don de / Gift of Umberto Riva
    When citing specific collection material, please refer to the object’s specific credit line.

    Folder Number:

    180-005-010
